Panel-Mounting Connectors (D)

Panel-Mounting Connectors

CDx-L1xxCSR

IP66~68

  • Contact Type : Male Solder Bucket Pin
  • Mounting Type : Rear Mounting,
  • Connector Type : Panel Mounting
  • Gender of Pins : Male
  • Locking System : Bayonet Locking
  • Number of Pins : 2 ,3 ,4 ,5 ,6 ,7 ,18
  • Rated Current : 5A ,20A

CDx-L1xxCPR

IP66~68

  • Contact Type : Male PCB DIP Pin
  • Mounting Type : Rear Mounting,
  • Connector Type : Panel Mounting
  • Gender of Pins : Male
  • Locking System : Bayonet Locking
  • Number of Pins : 2 ,3 ,4 ,5 ,6 ,7 ,18
  • Rated Current : 5A ,20A

CDGD-L33xCSR

IP66~68

  • Contact Type : Female Solder Bucket Pin
  • Mounting Type : Rear Mounting,
  • Connector Type : Panel Mounting
  • Gender of Pins : Female
  • Locking System : Bayonet Locking
  • Number of Pins : Hybrid 3 + 7 ,Hybrid 3 + 6 ,Hybrid 3 + 5 ,Hybrid 3 + 4 ,Hybrid 3 + 3 ,Hybrid 3 + 2
  • Rated Current : Hybrid 20A (Power) + 5A (Signal)

CDGD-L33xCPR

IP66~68

  • Contact Type : Female PCB DIP Pin
  • Mounting Type : Rear Mounting
  • Connector Type : Panel Mounting
  • Gender of Pins : Female
  • Locking System : Bayonet Locking
  • Number of Pins : 3 + 2, 3 + 3, 3 + 4, 3 + 5, 3 + 6, 3 + 7
  • Rated Current : 20A (Power) + 5A (Signal)

CDD-L318CSR

IP66~68

  • Contact Type : Female Solder Bucket Pin
  • Mounting Type : Rear Mounting
  • Connector Type : Panel Mounting
  • Gender of Pins : Female
  • Locking System : Bayonet Locking
  • Number of Pins : 18
  • Rated Current : 5A

CDD-L318CPR

IP66~68

  • Contact Type : Female PCB DIP Pin
  • Mounting Type : Rear Mounting
  • Connector Type : Panel Mounting
  • Gender of Pins : Female
  • Locking System : Bayonet Locking
  • Number of Pins : 18
  • Rated Current : 5A
